Publication 2711-UM014G-EN-P - September 2008 235
Specifications Appendix A
Character Sizes (Pixel size = 0.48 x 0.48 mm)
Display
Type Liquid Crystal Display (LCD) with integral
LED backlight (100,000 hour life)
Size 73 mm (w) x 42 mm (h)
2.87 in. (w) x 1.67 in. (h)
Pixels 128 x 64
Terminal Memory
Total Application Flash Memory 240K bytes (application screens)
Environment
Operating Temperature 0…55
°
C (32…131
°
F)
Storage Temperature -25…85
°
C (-4…188
°
F)
Relative Humidity (non-condensing) 5…95% at 0…55
°
C (32…131
°
F)
Heat Dissipation 6 Watts (13 BTU/HR)
Shock (operating/non-operating) 15 g/30 g
Vibration (operating) 2 g up to 2,000 Hz
Airborne Contaminants
(1)
(1) Only applicable to conformal coated products: 2711-K3A5L1K.
ANSI/ISA-S71.04-1985 severity level G3,
reference EN60654-4:1998 Class 3
Size in Pixels
width x height) Characters/Row Maximum Rows Dimensions in mm
Width x Height
4 x 6 31 10 1.9 x 2.9
6 x 8 20 7 2.9 x 3.8
6 x 16 20 3 2.9 x 7.7
6 x 24 20 2 2.9 x 11.5
12 x 8 10 7 5.8 x 3.8
12 x 16 10 3 5.8 x 7.7
12 x 24 10 2 5.8 x 11.5
18 x 8 6 7 8.6 x 3.8
18 x 16 6 3 8.6 x 7.7
18 x 24 6 2 8.6 x 11.5
