84 Publication 2711-UM014G-EN-P - September 2008
Chapter 3 Configuring the Terminal
Input Size
Displays the number of words (0…64) sent by the PanelView in an
I/O message. The default value is 0, which indicates that no input data
is exchanged with the scanner. This value is set by the downloaded
application.
Output Size
Displays the number of words (0…64) received by the PanelView in
an I/O message. The default value is 0, which indicates no output data
is exchanged with the scanner. This value is set by the downloaded
application.
Comm Status Indicator
•
solid fill - normal operating state
•
blinking - no communication established
•
no fill - hardware failure
Exit
Returns to the Configuration Mode menu.
DF1 Communication
The DF1 screen lets you display or modify DF1/full duplex
communication settings for a DF1 PanelView terminal.
IMPORTANT
Settings downloaded with a DF1 application have priority over
terminal settings and take effect immediately after the
download.
DF1 - Full Duplex
Handshaking
Communication
Parameters Baud Rate
No Parity
8 Data Bits
1 Stop Bit
9600
OFF
F1 F2
F16
EXIT
Error
CRC
F3
Detection
Node
64
F4 F5
Comm Fault
LED LED
Connected
DF1 - Full Duplex
N/8/1 F1 Comms
F4 EXIT F3 MORE
9600 F2 Baud
Typical DF1 Setup Screens
