Publication 2711-UM014G-EN-P - September 2008 47
Terminal Overview Chapter 1
# Feature Description
1 Brightness Control Adjusts the brightness of the color display.
2 Contrast Control Adjusts the contrast of the color display.
3 Nameplate Label Provides product information.
4 FAULT Status (Red) Indicates firmware or hardware faults.
5 COMM Status (Green) Indicates when communication is occurring.
6 Power Connection Terminals Connects to external power source.
7 DH-485 Communication Port Connects to an SLC or MicroLogix controller, DH-485 network, or Wallmount Power
Supply (Cat. No. 1747-NP1).
8 DH-485 Programming Connector Connects to a Personal Computer Interface Converter (Cat. No. 1747-PIC) for
transferring applications. Also connects to an SLC programmer, such as the
Hand-held Terminal (Cat. No. 1747-PT1).
9 RS-232 (DH-485) Communication Port Connects to the Channel 0 port of an SLC 5/03, 5/04, or 5/05 for point-to-point
DH-485 communication. Connects to a MicroLogix controller through an AIC+ Link
Coupler. Also connects to the RS-232 serial port of a computer for transferring
applications.
10 Remote I/O Port Connects to a scanner or sub-scanner on a remote I/O network.
11 DH+ Communication Port Connects to a PLC-5, SLC 5/04, or ControlLogix controller on a DH+ link.
12 DeviceNet Connector Connects to a DeviceNet network.
13 ControlNet Connector Connects to a ControlLogix controller (with 1756-CNB module) or PLC-5 on a
ControlNet network.
14 RS-232 (DF1) Communication Port Connects to a PLC, SLC or MicroLogix controller with a DF1 port.
15 Ethernet Connector Connects to a PLC-5E or SLC 5/05 controller, or a ControlLogix, MicroLogix, FlexLogix,
or CompactLogix (with appropriate bridge module) on an EtherNet/IP network.
16 RS-232 Printer/File Transfer Port Connects to a printer. On remote I/O, DH+, DF1, DeviceNet, EtherNet/IP, or
ControlNet terminals, this port also connects to the RS-232 port of a computer for
transferring applications.
The RS-232 port on the DH-485 or RS-232 (DH-485) terminal is used to connect a
printer but not for file transfers.
17 Memory Card Eject Button Ejects memory card from slot.
18 Memory Card Slot Accepts a memory card which stores applications.
19 Sealing Gasket Seals the front of the terminal to an enclosure or panel.
20 Reset Button Resets the terminal.
21 CRT Board Adjustments See the warning below.
ATTENTION
Only qualified service technicians should access the CRT board
adjustments. Failure to follow this caution could result in
electrical shock, a misadjusted monitor, or a damaged monitor.
