122 Publication 2711-UM014G-EN-P - September 2008
Chapter 5 Running Applications
ASCII Scratchpad - PV300 Micro/300 Terminals
The thumbwheel scratch pad lets you enter values on terminals
without a numeric keypad or touch screen by cycling through the
available characters one position at a time. This is the character
sequence:
The default scratchpad indicates . Press the Up or Down
cursor keys on a to cycle through the available characters,
beginning with A. Press the Down cursor to cycle back through the
list, beginning with 9.
The scratchpad has the following function keys.
>> F4 Function Keys Moves the cursor one character to the right in the Display Area.
ESC 5 Function Keys Closes the scratchpad without making any changes.
CTRL F6 Function Keys Clears the string in the Display Area.
Controls Location Function
Keys Function
F1 - ESC Exits the scratchpad without saving any changes or
sending characters to the logic controller.
F2 - Clear Clears all characters in the display area.
F3 - INS Inserts a space at the current cursor position.
F4 - DEL Deletes the character at the current cursor position.
A - Z, a - z, + - = ( ) [ ] { } < > / \ $ & @ ‘ “ , . ; : ? ! % # * _ ^ ~ ` ¬ ¡ ¿
Я ° £ з З µ в а б д Д к и й Й о м н С с ф т у ц Ц ы щ ъ ь Ь, 0 - 9
