Terminal Overview Chapter 1
Antiglare Overlay
Self-adhesive filters minimize the reflection of terminal displays.
DH-485 Operating and Programming Cables
(1)
Contact Rockwell Automation for availability.
Cat. No. 300M 300 550 600 900 1000 1400
2711-NV4 (Keypad) x
2711-NV4T (Touch Screen Terminals) x x
2711-NV3K (Keypad) x
2711-NV3T (Touch Screen Terminals) x
2711-NV5 (Keypad) x
2711-NV7K (Keypad Terminals) x
2711-NV7T (Touch Screen Terminals) x
2711-NV6K (Keypad Terminals) x
2711-NV6T (Touch Screen Terminals) x
2711-NV8 (Keypad Terminals) x
Cat. No. Description
1747-PIC Personal Computer Interface Converter converts RS-232 signals to/from RS-485 signals. Use to transfer
applications between a DH-485 terminal and a computer.
1747-C10 1.83 m (6 ft) cable connects a DH-485 terminal to an SLC or DH-485 network.
1747-C11 0.30 m (1 ft) cable connects a DH-485 terminal to an SLC or DH-485 network.
1747-C20 6.1 m (20 ft) cable connects a DH-485 terminal to an SLC or DH-485 network.
1747-CP3 45 cm (17.7 in.) cable connects an RS-232 terminal to an AIC+ (Port1) through a null modem adapter.
1761-CBL-AP00 45 cm (17.7 in.) cable connects an RS-232 terminal to an AIC+ (Port2) through a null modem adapter.
1761-CBL-AC00 3 m (9.8 ft) cable connects an RS-232 terminal to an AIC+ (Port1) through a null modem adapter.
1761-CBL-AS03 3 m (9.8 ft) cable connects a DH-485 terminal to an AIC+ (Port3).
1761-CBL-AS09 9.9 m (29.5 ft) cable connects a DH-485 terminal to an AIC+ (Port3).
1761-CBL-AM00 45 cm (17.7 in.) cable with 2 mini DIN, right angle connectors.
1761-CBL-HM02 2 m (6.5 ft) cable with 2 mini DIN, right angle connectors.
2711-CBL-HM05 5 m runtime cable with 2 mini DIN, right angle connectors.
2711-CBL-HM10 10 m runtime cable with 2 mini DIN, right angle connectors.
1761-CBL-PM00 45 cm (17.7 in.) cable connects an RS-232 terminal to an AIC+ (Port2) through a null modem adapter.
