Publication 2711-UM014G-EN-P - September 2008 237
Specifications Appendix A
Character Sizes (Pixel size = 0.47 x 0.47 mm)
Terminal Memory
PV550 (Series E or later) or
PV550T (Series A or later)
Total Application Flash Memory
240K bytes (application screens)
PV550 (Prior to Series E)
Total Application Flash Memory
112K bytes (application screens)
Environment
Operating Temperature 0…55
°
C (32…131
°
F)
Storage Temperature -20…70
°
C (-4…158
°
F)
Relative Humidity (non-condensing) 5…95% at 0…30
°
C (32…86
°
F)
5…75% at 31… 40
°
C (88…104
°
F)
5…50% at 41…55
°
C (106…131
°
F)
Heat Dissipation 20 W (69 BTU/HR) for AC Power or
DC Power
Shock (operating/non-operating) 30 g/50 g
Vibration (operating) 2 g up to 2,000 Hz
Size in Pixels
width x height) Characters/Row Maximum Rows Dimensions in mm
Width x Height
6 x 8 40 16 2.2 x 3.2
6 x 16 20 16 3.8 x 5.6
6 x 24 13 16 3.8 x 8.4
12 x 8 40 8 7.6 x 2.8
12 x 16 20 8 7.6 x 5.6
12 x 24 13 8 7.6 x 8.4
18 x 8 40 5 11.2 x 2.8
18 x 16 20 5 11.2 x 5.6
18 x 24 13 5 11.2 x 8.4
