Page 192
192
Publication 2711-UM014G-EN-P - September 2008
Chapter 12 Terminal Connections
DH-485 Terminal
Connections
This section describes connections for the DH-485 PanelView
terminals.
•
DH-485 terminal ports
•
Connecting to a single SLC controller (Point-to-point)
•
Connecting to a DH-485 network
•
Connecting a computer
•
Connecting a Hand-held terminal
DH-485 Terminal Ports (RJ45)
DH-485 PanelView terminals with catalog numbers ending in 2 have
two DH-485 ports. Terminals with catalog numbers ending in 3 also
have an RS-232 printer port.
Use the DH-485 communication port to:
•
communicate with a single or multiple SLC controllers over a
DH-485 network.
Use the DH-485 SLC Programming connector to:
•
upload/download PanelView applications.
•
monitor SLC operation, enter/modify SLC programs, test network
devices.
Use the RS-232 Printer port to:
•
connect a printer that supports the IBM enhanced character set.
For details on connecting to the RS-232 port, see the last section
in this chapter.
TIP
For PanelView 300 Micro terminals, refer to page 218.
