Appendix D
Configuration Data
D–13
Table D.9
Configuration Blocks #72–103 – Gages 1–32 (Toolset 2)
Remote I/O
& RS–232
Word #*
Bit #
Definition
Usage
Notes
4
8–15
High Threshold/Gradient Threshold
0 – 63
0 – 197
If binary operation, value is used as the
threshold high. If gray scale operation, value is
gradient threshold.
5
0–15
Reserved
6
0–15
Gage Head X Position
7
0–15
Gage Head Y Position
8
0–15
Gage Tail X Position
9
0–15
Gage Tail Y Position
10
0–15
Gage X Center Position
(Circular Gage)
11
0–15
Gage Y Center Position
(Circular Gage)
12
0–15
Radius of Circular Gage
13–16
0–15
Reserved
17
0–15
Fail Range High (Integer)
Words 17 and 18 represent a 16 (bit) . 16 (bit)
fixed point decimal value or 32 bit integer.
Refer to Appendix A.
18
0–15
Fail Range High (Fraction)
19
0–15
Fail Range Low (Integer)
Words 19 and 20 represent a 16 (bit) . 16 (bit)
fixed point decimal value or 32 bit integer.
Refer to Appendix A.
20
0–15
Fail Range Low (Fraction)
21
0–15
Warning Range High (Integer)
Words 21 and 22 represent a 16 (bit) . 16 (bit)
fixed point decimal value or 32 bit integer.
Refer to Appendix A.
22
0–15
Warning Range High (Fraction)
23
0–15
Warning Range Low (Integer)
Words 23 and 24 represent a 16 (bit) . 16 (bit)
fixed point decimal value or 32 bit integer.
Refer to Appendix A.
24
0–15
Warning Range Low (Fraction)
25–27
0–15
Reserved
* Refer to Chapter 6 for Pyramid Integrator long word descriptions.
