Appendix C
Numerical Results Data
C–3
Table C.1 shows the function of each word in Results Block #1.
Table C.1
Numerical Results Data – Results Block 1
Word #
PI Backplane
RS–232
and
Bit #
Definition
Usage
Notes
Toolset 1
Toolset 2
Remote
I/O
24
288
0
0 – 15
Block Transfer
Signature
25
289
1
0 – 15
Reserved
26
290
2
0 – 15
Brightness Probe
Integer
16 . 16 value. Refer to Appendix A.
27
291
3
0 – 15
Brightness Probe
Fraction
16 . 16 value. Refer to Appendix A.
28
292
4
0 – 15
Reference Line
#1X Position
From upper left corner of display. 16 bit integer.
29
293
5
0 – 15
Reference Line
#1Y Position
From upper left corner of display. 16 bit integer.
30
294
6
0 – 15
Reference Line
#2X Position
From upper left corner of display. 16 bit integer.
31
295
7
0 – 15
Reference Line
#2Y Position
From upper left corner of display. 16 bit integer.
32
296
8
0 – 15
Reference Line
#3X Position
From upper left corner of display. 16 bit integer.
33
297
9
0 – 15
Reference Line
#3Y Position
From upper left corner of display. 16 bit integer.
34
298
10
0 – 15
Reference Window
#1X1 Position
Feature #1. From upper left corner. 16 bit integer.
35
299
11
0 – 15
Reference Window
#1Y1 Position
Feature #1. From upper left corner. 16 bit integer.
36
300
12
0 – 15
Reference Window
#1X2 Position
Feature #2. From upper left corner. 16 bit integer.
37
301
13
0 – 15
Reference Window
#1Y2 Position
Feature #2. From upper left corner. 16 bit integer.
38
302
14
0 – 15
Reference Window
#1X3 Position
Feature #3. From upper left corner. 16 bit integer.
39
303
15
0 – 15
Reference Window
#1Y3 Position
Feature #3. From upper left corner. 16 bit integer.
40
304
16
0 – 15
Reference Window
#1X–Center
Centroid of enabled feature. 16 bit integer.
41
305
17
0 – 15
Reference Window
#1Y–Center
Centroid of enabled feature. 16 bit integer.
42
306
18
0 – 15
Reference Window
#1 Theta Integer
16 . 16 value. Refer to Appendix A. Only if 2 or 3
Features are enabled.
43
307
19
0 – 15
Reference Window
#1 Theta Faction
Only if 2 or 3 Features are enabled.
Results Block #1
