Appendix B

Discrete Bit Results

B–14

Table B.3
Discrete Bit Outputs

Word#

Bit#

PI Backplane

RS–232

and

Remote I/O

D
E
C

I

M
A

L

O
C

T

A

L

Definition

Usage

Notes

PI

PLC

4

2

8 – 11

10 – 13

Configuration
Move Control

0000 = No
Request

0001 = EEPROM
to RAM

0010 = RAM to
EEPROM

0100 = RAM
Card to RAM

1000 = RAM to
RAM Card

4

2

12 – 15

14 – 17

RAM Card Index

0000 = RAM
Card
Configuration 1

1111 = RAM
Card
Configuration 16

Bits 12 through 15 are numeric fields which specify
RAM card locations 1 through 16.

Discrete Bit Outputs (cont’d)
