Appendix D
Configuration Data

D–8

Table D.5
Configuration Blocks #10–41 – Gages 1–32 (Toolset 1)

Remote I/O

& RS–232

Word #*

Bit #

Definition

Usage

Notes

4

8–15

High Threshold/Gradient Threshold

0 – 63
0 – 197

If binary operation, value is used as the
threshold high. If gray scale operation, value is
gradient threshold.

5

0–15

Reserved

6

0–15

Gage Head X Position

7

0–15

Gage Head Y Position

8

0–15

Gage Tail X Position

9

0–15

Gage Tail Y Position

10

0–15

Gage X Center Position (Circular
Gage)

11

0–15

Gage Y Center Position (Circular
Gage)

12

0–15

Radius of Circular Gage

13–16

0–15

Reserved

17

0–15

Fail Range High (Integer)

Words 17 and 18 represent a 16(bit) . 16(bit)
fixed point decimal value or 32 bit integer.
Refer to Appendix A.

18

0–15

Fail Range High (Fraction)

19

0–15

Fail Range Low (Integer)

Words 19 and 20 represent a 16(bit) . 16(bit)
fixed point decimal value or 32 bit integer.
Refer to Appendix A.

20

0–15

Fail Range Low (Fraction)

21

0–15

Warning Range High (Integer)

Words 21 and 22 represent a 16(bit) . 16(bit)
fixed point decimal value or 32 bit integer.
Refer to Appendix A.

22

0–15

Warning Range High (Fraction)

23

0–15

Warning Range Low (Integer)

Words 23 and 24 represent a 16(bit) . 16(bit)
fixed point decimal value or 32 bit integer.
Refer to Appendix A.

24

0–15

Warning Range Low (Fraction)

25–27

0–15

Reserved

* Refer to Chapter 6 for Pyramid Integrator long word descriptions.

Configuration Blocks 10 – 41
(cont’d)
