Appendix D
Configuration Data

D–9

Table D.6 shows the function of each word in the window 1–24 (Toolset 1)
configuration blocks.

Table D.6
Configuration Blocks #42–65 – Windows 1–24 (Toolset 1)

Remote I/O

& RS–232

Word #

Bit #

Definition

Usage

Notes

0

0–15

Block Transfer Signature

1

0

Enable

0 = Disabled
1 = Enabled

1

1–15

Reserved

2–4

0–15

Reserved

5

0– 7

Window Low Threshold

0 = Low Limit
. . .
63 = High Limit

5

8–15

Window High Threshold

0 = Low Limit
. . .
63 = High Limit

6–10

0–15

Reserved

11

0–15

Window X Location (Bounding Box)

12

0–15

Window Y Location (Bounding Box)

13

0–15

Window Width (Bounding Box)

14

0–15

Window Height (Bounding Box)

15

0–15

Mask X Location (Bounding Box)

16

0–15

Mask Y Location (Bounding Box)

17

0–15

Mask Width (Bounding Box)

18

0–15

Mask Height (Bounding Box)

19–27

0–15

Reserved

28

0–15

Fail Range High (Integer)

Words 28 and 29 represent a 16(bit) . 16(bit)
fixed point decimal value or 32 bit integer.
Refer to Appendix A.

29

0–15

Fail Range High (Fraction)

30

0–15

Fail Range Low (Integer)

Words 30 and 31 represent a 16(bit) . 16(bit)
fixed point decimal value or 32 bit integer.
Refer to Appendix A.

31

0–15

Fail Range Low (Fraction)

32

0–15

Warning Range High (Integer)

Words 32 and 33 represent a 16(bit) . 16(bit)
fixed point decimal value or 32 bit integer.
Refer to Appendix A.

33

0–15

Warning Range High (Fraction)

34

0–15

Warning Range Low (Integer)

Words 34 and 35 represent a 16(bit) . 16(bit)
fixed point decimal value or 32 bit integer.
Refer to Appendix A.

35–36

0–15

Warning Range Low (Fraction)

* Refer to Chapter 6 for Pyramid Integrator long word descriptions.

Configuration Blocks 42 – 65
