Chapter 5
Using the RS-232 Ports
5–41
Use the Save command to save CVIM module configuration data to the local
storage area (EEPROM) or the external RAM card (credit card memory).
Note: Depending upon the card size, up to 16 configurations can be saved to
the RAM card (512K card).
Use the following commands:
Saves configuration to EEPROM.
XX
Where XX = card storage location (01 to 16).
This function can only be executed once per command. You cannot use the
commands when the CVIM module is in the SETUP mode.
If the BCC is not valid, the CVIM module will respond with a DLE NAK
and the command will not be executed.
If the BCC is valid, the CVIM module will respond with a DLE ACK. Then
the CVIM module will validate the command structure. If the command is
valid, the CVIM module will execute the command. If the command
structure is invalid, the CVIM module will not execute the command or
respond.
Use the display object command to control the image that is displayed on the
monitor. Use the following commands:
The data in this command specifies both the toolset and the display to be
viewed.
0B (hex) = Image only displayed – Toolset 1
0C (hex) = Failed tools displayed – Toolset 1
0D (hex) = All tools displayed – Toolset 1
0E (hex) = I/O page displayed – Toolset 1
0F (hex) = Results page displayed – Toolset 1
10 (hex) = Stats 1 page displayed – Toolset 1
Save Command
Select Image Displayed
