Appendix C
Numerical Results Data
C–8
Table C.3 shows the function of each word in results block #3.
Table C.3
Numerical Results Data – Results Block 3
Word #
PI Backplane
RS–232
and
Bit #
Definition Usage Notes
Toolset 1 Toolset 2
Remote
I/O
152 416 0 0 – 15
Block Transfer
Signature
153 417 1 0 – 15 Reserved
154 – 155 418 – 419 2 – 3 0 – 15 Gage #23 Value
Angular & Linear Measure – 16 . 16
Edge – 32 bit integer
Object – 32 bit integer
Pixel – 32 bit integer
X Position & Y Position – 16 . 16
156 – 157 420 – 421 4 – 5 0 – 15 Gage #24 Value Same as Gage #23
158 – 159 422 – 423 6 – 7 0 – 15 Gage #25 Value Same as Gage #23
160 – 161 424 – 425 8 – 9 0 – 15 Gage #26 Value Same as Gage #23
162 – 163 426 – 427 10 – 11 0 – 15 Gage #27 Value Same as Gage #23
164 – 165 428 – 429 12 – 13 0 – 15 Gage #28 Value Same as Gage #23
166 – 167 430 – 431 14 – 15 0 – 15 Gage #29 Value Same as Gage #23
168 – 169 432 – 433 16 – 17 0 – 15 Gage #30 Value Same as Gage #23
170 – 171 434 – 435 18 – 19 0 – 15 Gage #31 Value Same as Gage #23
172 – 173 436 – 437 20 – 21 0 – 15 Gage #32 Value Same as Gage #23
174 438 22 0 – 15
Reference Window
#2X1 Position
Feature #1 16 bit integer
175 439 23 0 – 15
Reference Window
#2Y1 Position
Feature #1 16 bit integer
176 440 24 0 – 15
Reference Window
#2X2 Position
Feature #2 16 bit integer
177 441 25 0 – 15
Reference Window
#2Y2 Position
Feature #2 16 bit integer
178 442 26 0 – 15
Reference Window
#2X3 Position
Feature #3 16 bit integer
179 443 27 0 – 15
Reference Window
#2Y3 Position
Feature #3 16 bit integer
180 444 28 0 – 15
Reference Window
#2X – Center
Centroid of enabled feature. 16 bit integer.
181 445 29 0 – 15
Reference Window
#2Y – Center
Centroid of enabled feature. 16 bit integer.
Results Block #3
