A

Appendix

A–1

Results/Configuration Data Overview

This appendix provides an overview of the word and bit addresses of data
stored in memory if you are communicating with the CVIM through the
REMOTE I/O, Backplane, or RS–232 port.

Also provided is an explanation of how the CVIM stores fractional data.

Table A.1 provides an overview of shared memory. Detailed descriptions of
each word and bit functions can be found in the other appendices:

Appendix B

— Discrete Results Bits

Appendix C

— Numerical Results Data

Appendix D

— Configuration Data

Block Name

Backplane Word #

XSD13i*

Backplane Word #

Handshake

0

N/A

Reserved

1

N/A

Discrete I/O Outputs

(Host Command Block)

2 to 9

O:20 to O:27

Reserved

10 to 15

N/A

Discrete I/O Inputs (TS1)

(Tool Inspection Results)

16 to 23

I:20 to I:27

Results Block 1 (TS1)

24 to 87

0 to 63

Results Block 2 (TS1)

88 to 151

0 to 63

Results Block 3 (TS1)

152 to 215

0 to 63

Results Block 4 (TS1)

216 to 279

0 to 63

Discrete I/O Inputs (TS2)

(Tool Inspection Results)

280 to 287

I:20 to I:27

Results Block 1 (TS2)

288 to 351

0 to 63

Results Block 2 (TS2)

352 to 415

0 to 63

Results Block 3 (TS2)

416 to 479

0 to 63

Results Block 4 (TS2)

480 to 543

0 to 63

Reserved

544 to 1022

0 to 63

Interrupt Control Word

1023

N/A

Configuration and Templates

Not Applicable

Not Applicable

Introduction

Overview
