Appendix D
Configuration Data

D–3

Table D.1
Configuration Block #1– System Environment (cont’d)

Remote I/O

& RS–232

Word #*

Bit #

Definition

Usage

Notes

14–15

0–15

Reserved

16

0–7

Toolset Display Status

0 = Disabled
1 = Enabled

All tools appear simultaneously while setting a
given tool.

16

8–15

Reserved

17

0–7

Reserved

17

8

Learn Mode

0 = Disabled
1 = Enabled

17

9

Outputs Enable

0 = Disabled
1 = Enabled

17

10

Freeze Enable

0 = Disabled
1 = Enabled

17

11

Halt Enable

0 = Disabled
1 = Enabled

17

12–15

Runtime Toolset Display

0 = Toolset 1
1 = Toolset 2

18–31

0–15

Reserved

32

0–15

Toolset 1 Pulse Width

In milliseconds.

33

0–15

Toolset 2 Pulse Width

In milliseconds.

34–44

0–15

Reserved

* Refer to Chapter 6 for Pyramid Integrator long word descriptions.
