Appendix D
Configuration Data

D–12

Table D.8
Configuration Blocks #69–71 – Reference Windows 1–3 (Toolset 2)

Remote I/O

& RS–232

Word #*

Bit #

Definition

Usage

Notes

19

0–15

Feature 2 Search Window Width

20

0–15

Feature 2 Search Window Height

21–24

0–15

Reserved

25

0–7

Reserved

25

8–15

Feature 2 Score

0 = Minimum Value
255 = Maximum Value

26

0–15

Feature 3 Search Window X
Location

Relative to the upper left corner.

27

0–15

Feature 3 Search Window Y
Location

Relative to the upper left corner.

28

0–15

Feature 3 Search Window Width

29

0–15

Feature 3 Search Window Height

30–33

0–15

Reserved

34

0–7

Reserved

34–35

8–15

Feature 3 Score

0 = Minimum Value
255 = Maximum Value

* Refer to Chapter 6 for Pyramid Integrator long word descriptions.

Table D.9 shows the function of each word in the gage 1–32 (Toolset 2)
configuration blocks.

Table D.9
Configuration Blocks #72–103 – Gages 1–32 (Toolset 2)

Remote I/O

& RS–232

Word #*

Bit #

Definition

Usage

Notes

0

0–15

Block Transfer Signature

1

0

Enable

0 = Disabled
1 = Enabled

1

1–15

Reserved

2–3

0–15

Reserved

4

0–7

Low Threshold/Gray Scale Factor

0 – 63
0 – 39

If binary operation, value is used as the
threshold. If gray scale operation, value is
scale factor.

* Refer to Chapter 6 for Pyramid Integrator long word descriptions.

Configuration Blocks 69–71
(cont’d)

Configuration Blocks 72–103
