Tables D.3 shows the function of each word in the reference line 1–3
(Toolset 1) configuration blocks.
Table D.3
Configuration Blocks #4–6 – Reference Lines 1–3 (Toolset 1)
Remote I/O
& RS–232
Word #*
Bit #
Definition
Usage
Notes
0
0–15
Block Transfer Signature
1
0–7
Reserved
1
8
Enable
0 = Disabled
1 = Enabled
1
9–15
Reserved
2–7
0–15
Reserved
8
0–7
X–Line Low Threshold/Gray Scale
Factor
0 – 63
0 – 39
If binary operation, value is used as the
threshold. If gray scale operation, value is
scale factor.
8
8–15
X–Line High Threshold/Gradient
Threshold
0 – 63
0 – 197
If binary operation, value is used as the
threshold high. If gray scale operation, value is
gradient threshold.
9
0–15
Reserved
10
0–15
X–Line Head X Position
From upper left corner.
11
0–15
X–Line Head Y Position
From upper left corner.
12
0–15
X–Line Tail X Position
From upper left corner.
13
0–15
X–Line Tail Y Position
From upper left corner.
14
0–15
Reserved
15
0–7
Y–Line Low Threshold/Gray Scale
Factor
0 – 63
0 – 39
If binary operation, value is used as the
threshold. If gray scale operation, value is
scale factor.
15
8–15
Y–Line High Threshold/Gradient
Threshold
0 – 63
0 – 197
If binary operation, value is used as the
threshold high. If gray scale operation, value is
gradient threshold.
16
0–15
Reserved
17
0–15
Y–Line Head X Position
From upper left corner.
18
0–15
Y–Line Head Y Position
From upper left corner.
19
0–15
Y–Line Tail X Position
From upper left corner.
20
0–15
Y–Line Tail Y Position
From upper left corner.
21
0–15
Reserved
22
0–7
X/Y–Line Low Threshold/Gray
Scale Factor
0 – 63
0 – 39
If binary operation, value is used as the
threshold. If gray scale operation, value is
scale factor.
22
8–15
X/Y–Line High Threshold/Gradient
Threshold
0 – 63
0 – 197
If binary operation, value is used as the
threshold high. If gray scale operation, value is
gradient threshold.
* Refer to Chapter 6 for Pyramid Integrator long word descriptions.
