Numerical Results Data

There are 4 results blocks for each toolset. The following is an overview of
the blocks.

Block Number 1 Contains:

Block Transfer Signature

Discrete Output Copy

Brightness Probe

X/Y Reference Lines #1, #2, and #3

Feature Finder #1

Windows 1–8

Gages 1–8

Total Number of Triggers, Missed Triggers, and Master Faults

Block #2 Contains:

Block Transfer Signature

Windows 9–16

Gages 9–22

Windows 17–24

Total Number of Triggers

Block #3 Contains:

Block Transfer Signature

Gages 23–32

Feature Finders #2 and #3

Total Number of Triggers, Missed Triggers, and Master Faults

Block #4 (Remote I/O Port only) Contains:

Block Transfer Signature

Status Word

User Programmable Block Transfer Data

Total Number of Triggers

Results Block Overview
