Chapter 6

Using the Pyramid Integrator Backplane

6–3

If you are using the Pyramid Integrator backplane for communications, you
must configure the CVIM module as follows:

7. Select the trigger source menu for the appropriate toolset

Source>.

8. Select either , trigger sources or .

Note: When changing the host to/from the Pyramid Integrator, you must
“pick” the selection twice and then reboot the CVIM module. Make sure
that you save your configuration first!

If you are accessing results through a PLC–5/250, the 1024 words of shared
memory are numbered 0 through 1023. The PLC–5/250 treats the shared
memory area like an integer file. Table 6.A provides a summary of the data.
Refer to Appendix A, B, or C for more detailed information.

Table 6.A
Shared Memory Overview

Block Name

Backplane Word #

Handshake

0

Reserved

1

Discrete I/O Outputs

(Host Command Block)

2 to 9

Reserved

10 to 15

Discrete I/O Inputs (TS1)

(Tool Inspection Results)

16 to 23

Results Block 1 (TS1)

24 to 87

Results Block 2 (TS1)

88 to 151

Results Block 3 (TS1)

152 to 215

Results Block 4 (TS1)

216 to 279

Dicrete I/O Inputs (TS2)

(Tool Inspection Results)

280 to 287

Results Block 1 (TS2)

288 to 351

Results Block 2 (TS2)

352 to 415

Results Block 3 (TS2)

416 to 479

Results Block 4 (TS2)

480 to 543

Reserved

544 to 1022

Interrupt Control Word

1023

Configuration and Templates

Not Applicable

Obtaining Inspection Result
Information Using a PLC–5/250
