Appendix B

Discrete Bit Results

B–12

Table B.3
Discrete Bit Outputs

Word#

Bit#

PI Backplane

RS–232

and

Remote I/O

D
E
C

I

M
A

L

O
C

T

A

L

Definition

Usage

Notes

PI

PLC

3

1

0 – 7

0 – 7

Runtime Display

Control

00000000 = No
Change

00000001 =
Display Image
Only

00000010 =
Display Failed
Tool

00000100 =
Display All Tools

00001000 =
Display I/O Page

00010000 =
Display Results
Page

00100000 =
Display Statistics
1 Page

01000000 =
Display Statistic
2 Page

Discrete Bit Outputs (cont’d)
