Appendix C
Numerical Results Data
C–5
Table C.1
Numerical Results Data – Results Block 1 (cont’d)
Word #
PI Backplane
RS–232
and
Bit #
Definition Usage Notes
Toolset 1 Toolset 2
Remote
I/O
64 – 65 328 – 329 40 – 41 0 – 15 Gage #1 Value
Angular & Linear Measure – 16 . 16
Edge – 32 bit integer
Object – 32 bit integer
Pixel – 32 bit integer
X Position & Y Position – 16 . 16
66 – 67 330 – 331 42 – 43 0 – 15 Gage #2 Value Same as Gage #1.
68 – 69 332 – 333 44 – 45 0 – 15 Gage #3 Value Same as Gage #1.
70 – 71 334 – 335 46 – 47 0 – 15 Gage #4 Value Same as Gage #1.
72 – 73 335 – 336 48 – 49 0 – 15 Gage #5 Value Same as Gage #1.
74 – 75 337 – 338 50 – 51 0 – 15 Gage #6 Value Same as Gage #1.
76 – 77 339 – 340 52 – 53 0 – 15 Gage #7 Value Same as Gage #1.
78 – 79 341 – 342 54 – 55 0 – 15 Gage #8 Value Same as Gage #1.
80 344 56 0 – 15 Reserved
81 345 57 0 – 15 Reserved
82 346 58 0 – 15 Reserved
83 347 59 0 – 15 Missed Triggers
84 348 60 0 – 15
Task Master Faults
– Most Significant
Word
32 bit integer. Value is incremented if at least one tool
fails.
85 349 61 0 – 15
Task Master Faults
– Least Significant
Word
86 350 62 0 – 15
Task Triggers –
Most Significant
Word
32 bit integer.
87 351 63 0 – 15
Task Triggers –
Least Significant
Word
