Appendix C
Numerical Results Data
C–6
Table C.2 shows the function of each word in results block #2.
Table C.2
Numerical Results Data – Results Block 2
Word #
PI Backplane
RS–232
and
Bit #
Definition Usage Notes
Toolset 1 Toolset 2
Remote
I/O
88 352 0 0 – 15
Block Transfer
Signature
89 353 1 0 – 15 Reserved
90 – 91 354 – 355 2 – 3 0 – 15 Window #9 Value
Luminance – 16 . 16
Object – 32 bit integer
Pixel – 32 bit integer
Template – 32 bit integer
Gradient – 32 bit integer
92 – 93 356 – 357 4 – 5 0 – 15 Window #10 Value Same as Window #9.
94 – 95 358 – 359 6 – 7 0 – 15 Window #11 Value Same as Window #9.
96 – 97 360 – 361 8 – 9 0 – 15 Window #12 Value Same as Window #9.
98 – 99 362 – 363 10 – 11 0 – 15 Window #13 Value Same as Window #9.
100 – 101 364 – 365 12 – 13 0 – 15 Window #14 Value Same as Window #9.
102 – 103 366 – 367 14 – 15 0 – 15 Window #15 Value Same as Window #9.
104 – 105 368 – 369 16 – 17 0 – 15 Window #16 Value Same as Window #9.
106 – 107 370 – 371 18 – 19 0 – 15 Gage #9 Value
Angular & Linear Measure – 16 . 16
Edge – 32 bit integer
Object – 32 bit integer
Pixel – 32 bit integer
X Position & Y Position – 16 . 16
108 – 109 372 – 373 20 – 21 0 – 15 Gage #10 Value Same as Gage #9.
110 – 111 374 – 375 22 – 23 0 – 15 Gage #11 Value Same as Gage #9.
112 – 113 376 – 377 24 – 25 0 – 15 Gage #12 Value Same as Gage #9.
114 – 115 378 – 379 26 – 27 0 – 15 Gage #13 Value Same as Gage #9.
116 – 117 380 – 381 28 – 29 0 – 15 Gage #14 Value Same as Gage #9.
118 – 119 382 – 383 30 – 31 0 – 15 Gage #15 Value Same as Gage #9.
120 – 121 384 – 385 32 – 33 0 – 15 Gage #16 Value Same as Gage #9.
122 – 123 386 – 387 34 – 35 0 – 15 Window #17 Value
Luminance – 16 . 16
Object – 32 bit integer
Pixel – 32 bit integer
Template – 32 bit integer
Gradient – 32 bit integer
124 – 125 388 – 389 36 – 37 0 – 15 Window #18 Value Same as Window #17.
126 – 127 390 – 391 38 – 39 0 – 15 Window #19 Value Same as Window #17.
Results Block #2
