Rockwell Automation 5370 CVIM Communications Manual User Manual
Page 150
Appendix B
Discrete Bit Results
B–5
Table B.1
Discrete Bit Inputs
Word#
Bit#
PI Backplane
RS–232
and
Remote
I/O
D
E
C
I
M
A
L
O
C
T
A
L
Definition
Usage
Notes
Toolset 1
Toolset 2
PI
PLC
19
283
3
7
7
Widow 20
Fault Flag
0 = Pass
1 = Fail
19
283
3
8
10
Window 21
Warning Flag
0 = Pass
1 = Fail
19
283
3
9
11
Window 21
Fault Flag
0 = Pass
1 = Fail
19
283
3
10
12
Window 22
Warning Flag
0 = Pass
1 = Fail
19
283
3
11
13
Window 22
Fault Flag
0 = Pass
1 = Fail
19
283
3
12
14
Window 23
Warning Flag
0 = Pass
1 = Fail
19
283
3
13
15
Window 23
Fault Flag
0 = Pass
1 = Fail
19
283
3
14
16
Window 24
Warning Flag
0 = Pass
1 = Failed
19
283
3
15
17
Window 24
Fault Flag
0 = Pass
1 = Failed
20
284
4
0
0
Gage 1
Warning Flag
0 = Pass
1 = Failed
20
284
4
1
1
Gage 1
Fault Flag
0 = Pass
1 = Failed
20
284
4
2
2
Gage 2
Warning Flag
0 = Pass
1 = Failed
20
284
4
3
3
Gage 2
Fault Flag
0 = Pass
1 = Failed
20
284
4
4
4
Gage 3
Warning Flag
0 = Pass
1 = Failed
20
284
4
5
5
Gage 3
Fault Flag
0 = Pass
1 = Failed
20
284
4
6
6
Gage 4
Warning Flag
0 = Pass
1 = Failed
20
284
4
7
7
Gage 4
Fault Flag
0 = Pass
1 = Failed
20
284
4
8
10
Gage 5
Warning Flag
0 = Pass
1 = Failed
20
284
4
9
11
Gage 5
Fault Flag
0 = Pass
1 = Failed
