Appendix D
Configuration Data

D–4

Tables D.2 shows the function of each word in the camera definition
configuration blocks.

Table D.2
Configuration Block #2 & 3 – Camera Definition

Remote I/O

& RS–232

Word #*

Bit #

Definition

Usage

Notes

0

0–15

Block Transfer Signature

1

0–7

Camera Low Reference

0 = Minimum Value
. . .
100 = Maximum Value

These values do not correspond with the
display on the help screen.

1

8–15

Camera High Reference

105 = Minimum Value
. . .
255 = Maximum Value

These values do not correspond with the
display on the help screen.

2

0–7

Light Probe Status

0 = Disabled
1 = Same Field
2 = Next Field

2

8–15

Reserved

3


0–15

Light Probe X Location

16 = Minimum Value
. . .
504 = Maximum Value

4

0–15

Light Probe Y Location

8 = Minimum Value
. . .
232 = Maximum Value

5–9

0–15

Reserved

10

0–15

Fail Range High (Integer)

Words 10 and 11 represent a 16 (bit) . 16 (bit)
fixed point decimal value.

11

0–15

Fail Range High (Fraction)

12

0–15

Fail Range Low (Integer)

Words 12 and 13 represent a 16(bit) . 16(bit)
fixed point decimal value.

13

0–15

Fail Range Low (Fraction)

14

0–15

Warning Range High (Integer)

Words 14 and 15 represent a 16 (bit). 16 (bit)
fixed point decimal value.

15

0–15

Warning Range High (Fraction)

16

0–15

Warning Range Low (Integer)

Words 16 and 17 represent a 16 (bit) . 16 (bit)
fixed point decimal value.

17

0–15

Warning Range Low (Fraction)

18–60

0–15

Reserved

* Refer to Chapter 6 for Pyramid Integrator long word descriptions.

Configuration Blocks 2 & 3
