Appendix D
Configuration Data

D–11

Table D.7
Configuration Blocks #37–39 – Reference Lines 1–3 (Toolset 2)

Remote I/O

& RS–232

Word #

Bit #

Definition

Usage

Notes

23

0–15

Reserved

24

0–15

X/Y–Line Head X Position

From upper left corner.

25

0–15

X/Y–Line Head Y Position

From upper left corner.

26

0–15

X/Y–Line Tail X Position

From upper left corner.

27

0–15

X/Y–Line Tail Y Position

From upper left corner.

28–29

0–15

Reserved

* Refer to Chapter 6 for Pyramid Integrator long word descriptions.

Table D.8 shows the function of each word in the reference window 1–3
(Toolset 2) configuration blocks.

Table D.8
Configuration Blocks #69–71 – Reference Windows 1–3 (Toolset 2)

Remote I/O

& RS–232

Word #*

Bit #

Definition

Usage

Notes

0

0–15

Block Transfer Signature

1

0–7

Reserved

1

8

Enable

0 = Disabled

1

8

Enable

0 = Disabled
1 = Enabled

1

9–15

Reserved

2–7

0– 15

Reserved

8

0– 15

Feature 1 Search Window X
Location

Relative to the upper left corner.

9

0– 15

Feature 1 Search Window Y
Location

Relative to the upper left corner.

10

0– 15

Feature 1 Search Window Width

11

0– 15

Feature 1 Search Window Height

12–15

0–15

Reserved

16

0–7

Reserved

16

8–15

Feature 1 Score

0 = Minimum Value
255 = Maximum Value

17

0–15

Feature 2 Search Window X
Location

Relative to the upper left corner.

18

0–15

Feature 2 Search Window Y
Location

Relative to the upper left corner.

* Refer to Chapter 6 for Pyramid Integrator long word descriptions.
