Appendix B

Discrete Bit Results

B–11

Table B.3
Discrete Bit Outputs

Word #

Bit #

PI Backplane

RS–232

and

Remote I/O

D
E
C

I

M
A

L

O
C

T

A

L

Definition

Usage

Notes

PI

PLC

2

0

13

15

I/O Request

0 = No Request
1 = Request

Bit 13 commands are specified in:

Output words 2, 4, and 5 (Remote I/O)

Output words 4, 6, and 7 (Backplane)

You must reset bit to 0, then back to 1 to repeat an
I/O request.

2

0

14

16

Configuration

Move

0 = No Request
1 = Request

Bit 14 commands are specified in:

Output word 2 (Remote I/O)

Output word 4 (Backplane)

You must reset bit to 0, then back to 1 to repeat a
configuration move request.

2

0

15

17

Not Used
