Appendix B

Discrete Bit Results

B–18

Table B.3
Discrete Bit Outputs

Word#

Bit#

PI Backplane

RS–232

and

Remote I/O

D
E
C

I

M
A

L

O
C

T

A

L

Definition

Usage

Notes

PI

PLC

8

6

0 – 1

0 – 1

Toolset Display
Control

00 = No Change
01 = Display
Toolset 1
10 = Display
Toolset 2

8

6

2

2

Not Used

8

6

3

3

Resume Control

0 = No Change
1 = Resume

Use in conjunction with light pen request:
Word 0 bit 12 (Remote)
Word 2 bit 12 (Backplane)

8

6

4 – 5

4 – 5

Page Control

00 = No Change
01 = Page Up
10 = Page Down

Use in conjunction with light pen request:
Word 0 bit 12 (Remote)
Word 2 bit 12 (Backplane)

8

6

6

6

Reset Statistics

0 = No Change
1 = Reset

Use in conjunction with light pen request:
Word 0 bit 12 (Remote)
Word 2 bit 12 (Backplane)

8

6

7

7

Reset Counters

0 = No Change
1 = Reset

Use in conjunction with light pen request:
Word 0 bit 12 (Remote)
Word 2 bit 12 (Backplane)

8

6

8 – 15

10 – 17

Not Used

Discrete Bit Outputs (cont’d)
