Appendix C
Numerical Results Data
C–9
Table C.3
Numerical Results Data – Results Block 3
Word #
PI Backplane
RS–232
and
Bit #
Definition Usage Notes
Toolset 1 Toolset 2
Remote
I/O
182 446 30 0 – 15
Reference Window
#2 Theta (Integer)
16 . 16 value. Refer to Appendix A. Only if 2 or 3
features are enabled.
183 447 31 0 – 15
Reference Window
#2 (Fraction)
Only if 2 or 3 features are enabled.
184 448 32 0
Reference Window
#2X1/Y1 Pass/Fail
Bit
0 = Pass
1 = Fail
Feature #1.
184 448 32 1
Reference Window
#2X2/Y2 Pass/Fail
Bit
0 = Pass
1 = Fail
Feature #2.
184 448 32 2
Reference Window
#2X3/Y3 Pass/Fail
Bit
0 = Pass
1 = Fail
Feature #3.
184 448 32 3
Combination
Pass/Fail Bit
0 = Pass
1 = Fail
0 if all enabled features pass.
184 448 32 4 – 15 Not Used
185 449 33 0 – 15
Score Reference
Window #2,
Feature #1
186 450 34 0 – 15
Score Reference
Window #2,
Feature #2
187 451 35 0 – 15
Score Reference
Window #2,
Feature #3
188 452 36 0 – 15
Reference Window
#3X1 Position
Feature #1 16 bit integer.
189 453 37 0 – 15
Reference Window
#3Y1 Position
Feature #1 16 bit integer.
190 454 38 0 – 15
Reference Window
#3X2 Position
Feature #2 16 bit integer.
191 455 39 0 – 15
Reference Window
#3Y2 Position
Feature #2 16 bit integer.
192 456 40 0 – 15
Reference Window
#3X3 Position
Feature #3 16 bit integer.
193 457 41 0 – 15
Reference Window
#3Y3 Position
Feature #3 16 bit integer.
