Appendix B
Discrete Bit Results
B–7
Table B.1
Discrete Bit Inputs
Word# Bit#
PI Backplane
RS–232
and
Remote
I/O
D
E
C
I
M
A
L
O
C
T
A
L
Definition Usage Notes
Toolset 1 Toolset 2 PI PLC
21 285 5 13 15
Gage 15
Fault Flag
0 = Pass
1 = Fail
21 285 5 14 16
Gage 16
Warning Flag
0 = Pass
1 = Fail
21 285 5 15 17
Gage 16
Fault Flag
0 = Pass
1 = Fail
22 286 6 0 0
Gage 17
Warning Flag
0 = Pass
1 = Fail
22 286 6 1 1
Gage 17
Fault Flag
0 = Pass
1 = Fail
22 286 6 2 2
Gage 18
Warning Flag
0 = Pass
1 = Failed
22 286 6 2 2
Gage 18
Fault Flag
0 = Pass
1 = Failed
22 286 6 3 3
Gage 19
Warning Flag
0 = Pass
1 = Failed
22 286 6 4 4
Gage 19
Fault Flag
0 = Pass
1 = Failed
22 286 6 5 5
Gage 20
Warning Flag
0 = Pass
1 = Failed
22 286 6 7 7
Gage 20
Fault Flag
0 = Pass
1 = Failed
22 286 6 8 10
Gage 21
Warning Flag
0 = Pass
1 = Failed
22 286 6 9 11
Gage 21
Fault Flag
0 = Pass
1 = Failed
22 286 6 10 12
Gage 22
Warning Flag
0 = Pass
1 = Failed
22 286 6 11 13
Gage 22
Fault Flag
0 = Pass
1 = Failed
22 286 6 12 14
Gage 23
Warning Flag
0 = Pass
1 = Failed
22 286 6 13 15
Gage 23
Fault Flag
0 = Pass
1 = Failed
22 286 6 14 16
Gage 24
Warning Flag
0 = Pass
1 = Failed
22 286 6 15 17
Gage 24
Fault Flag
0 = Pass
1 = Failed
