Select Command and Status Bits
to Sequence Machine Operation
Chapter 6
6-7
Table
6.I
(continued)
Category:
Bit Status
(when = 1):
QDC Block
Addr.:
ProĆSet
Addr.:
Watchdog Status
1st clamp close watchdog timed out
SYS04ĆB00
B35/48
2nd clamp close watchdog timed out SYS04ĆB01
B35/49
3rd clamp close watchdog timed out
SYS04ĆB02
B35/50
LP close watchdog timed out
SYS04ĆB03
B35/51
1st clamp open watchdog timed out
SYS04ĆB10
B35/58
2nd clamp open watchdog timed out
SYS04ĆB11
B35/59
3rd clamp open watchdog timed out
SYS04ĆB12
B35/60
clamp open slow watchdog timed out SYS04ĆB13
B35/61
ejector watchdog timed out
SYS04ĆB14
B35/62
tonnage watchdog timed out
SYS04ĆB15
B35/63
Profile Status
executing 1st close profile
SYS21ĆB00
B35/320
executing 2nd close profile
SYS21ĆB01
B35/321
executing 3rd close profile
SYS21ĆB02
B35/322
executing LP close profile
SYS21ĆB03
B35/323
executing 1st clamp open profile
SYS21ĆB10
B35/330
executing 2nd clamp open profile
SYS21ĆB11
B35/331
executing 3rd clamp open profile
SYS21ĆB12
B35/332
executing clamp open slow profile
SYS21ĆB13
B35/333
executing ejector profile
SYS21ĆB14
B35/334
EndĆof Profile
SetĆoutput Status
executing endĆof 1st clamp close
setĆoutput
SYS22ĆB00
B35/336
executing endĆof 2nd clamp close
setĆoutput
SYS22ĆB01
B35/337
executing endĆof 3rd clamp close
setĆoutput
SYS22ĆB02
B35/338
executing endĆof LP close setĆoutput SYS22ĆB03
B35/339
executing endĆof 1st clamp open
setĆoutput
SYS22ĆB10
B35/346
executing endĆof 2nd clamp open
setĆoutput
SYS22ĆB11
B35/347
executing endĆof 3rd clamp open
setĆoutput
SYS22ĆB12
B35/348
executing endĆof clamp open slow
setĆoutput
SYS22ĆB13
B35/349
executing endĆof ejector advance
setĆoutput
SYS22ĆB14
B35/350
executing endĆof ejector retract
setĆoutput
SYS22ĆB15
B35/351
