Select Command and Status Bits
to Sequence Machine Operation
Chapter 6
6-2
Table 6.A lists the tables included in this chapter along with specific
information found in each:
Table 6.A
Bit Table Summary
Type of Function:
What the Table Contains:
How You Implement Commands:
Table
6.B
Manual (nonĆprofiled) Command and status bits to control and monitor
manual jog, direct setĆoutput, and stop
To enable: set command bit (0 to 1)
To terminate: reset command bit (1 to 0)
Table
6.C
Automatic (profiled)
Command bits to control profiles
To enable: toggle command bit (0 to 1 to 0).
Terminated by the QDC module automatically.
To force early termination: set stop bit (0 to 1),
or initiate another automatic function.
Table
6.D
Automatic (profiled)
Status and command bits to link automatic
functions during a machine cycle
Input conditions and permissives to initiate
subsequent machine movements:
(1 = enabled, 0 = disabled)
Table
6.E
Automatic (profiled)
Command bits to interrupt clamp movement
see table
Table
6.F
Automatic (profiled)
Miscellaneous status bits to trigger clamp action 0 = disabled, 1 = enabled
Table
6.G
Automatic (profiled)
Command bits to enable/disable ejector profiles see table
Table
6.H
Automatic (profiled)
Miscellaneous status bits to trigger ejector
action
0 = disabled, 1 = enabled
Table
6.I
---
Status bits for clamp and eject mode
see table
Table
6.J
---
Command bits for clamp and eject mode
see table
Table 6.B
Command and Status Bits for Manual Control in Clamp and Eject Mode
To Initiate this action:
Set this bit:
The QDC module sets this
bit during execution:
Unassigned # 1 Jog
DYC01ĆB09
SYS01ĆB09
Unassigned # 2 Jog
DYC01ĆB10
SYS01ĆB010
Unassigned # 3 Jog
DYC01ĆB11
SYS01ĆB11
Clamp Forward Jog
DYC01ĆB12
SYS01ĆB12
Clamp Reverse Jog
DYC01ĆB13
SYS01ĆB13
Ejector Advance Jog
DYC01ĆB14
SYS01ĆB14
Ejector Retract Jog
DYC01ĆB15
SYS01ĆB15
Direct SetĆoutput
DYC01ĆB08
SYS01ĆB08
Stop
DYC02ĆB15
SYS02ĆB15
