Enter Your Values Here
Load Initial Profile Values for
Machine Tuning
Chapter 8
8-3
Worksheet 8-A
(continued)
Clamp Close (CPC) Profile Block
Control Word ProĆSet 600 Addr. Value Description Units
CPC09 N43:245 0 FCC Segment 1 Velocity Setpoint Percent of Maximum Velocity 1 or
Velocity along Axis 2
CPC10 N43:246 0 FCC Segment 1 Pressure Setpoint Pressure 3
CPC11 N43:247 * FCC EndĆofĆSegment 1 Position Setpoint Incremental Distance 4
CPC12 N43:248 0 FCC Segment 2 Velocity Setpoint Percent of Maximum Velocity 1 or
Velocity along Axis 2
CPC13 N43:249 0 FCC Segment 2 Pressure Setpoint Pressure 3
CPC14 N43:250 * FCC EndĆofĆSegment 2 Position Setpoint Incremental Distance 4
CPC15 N43:251 0 FCC Segment 3 Velocity Setpoint Percent of Maximum Velocity 1 or
Velocity along Axis 2
CPC16 N43:252 0 FCC Segment 3 Pressure Setpoint Pressure 3
CPC17 N43:253 * FCC EndĆofĆSegment 3 Position Setpoint Incremental Distance 4
CPC18 N43:254 0 SCC Segment 1 Velocity Setpoint Percent of Maximum Velocity 1 or
Velocity along Axis 2
CPC19 N43:255 0 SCC Segment 1 Pressure Setpoint Pressure 3
CPC20 N43:256 0 SCC EndĆofĆSegment 1 Position Setpoint Incremental Distance 4
CPC21 N43:257 0 SCC Segment 2 Velocity Setpoint Percent of Maximum Velocity 1 or
Velocity along Axis 2
CPC22 N43:258 0 SCC Segment 2 Pressure Setpoint Pressure 3
CPC23 N43:259 0 SCC EndĆofĆSegment 2 Position Setpoint Incremental Distance 4
CPC24 N43:260 0 SCC Segment 3 Velocity Setpoint Percent of Maximum Velocity 1 or
Velocity along Axis 2
CPC25 N43:261 0 SCC Segment 3 Pressure Setpoint Pressure 3
CPC26 N43:262 0 SCC EndĆofĆSegment 3 Position Setpoint Incremental Distance 4
CPC27 N43:263 0 TCC Segment 1 Velocity Setpoint Percent of Maximum Velocity 1 or
Velocity along Axis 2
CPC28 N43:264 0 TCC Segment 1 Pressure Setpoint Pressure 3
CPC29 N43:265 0 TCC EndĆofĆSegment 1 Position Setpoint Incremental Distance 4
CPC30 N43:266 0 TCC Segment 2 Velocity Setpoint Percent of Maximum Velocity 1 or
Velocity along Axis 2
CPC31 N43:267 0 TCC Segment 2 Pressure Setpoint Pressure 3
CPC32 N43:268 0 TCC EndĆofĆSegment 2 Position Setpoint Incremental Distance 4
CPC33 N43:269 0 TCC Segment 3 Velocity Setpoint Percent of Maximum Velocity 1 or
Velocity along Axis 2
CPC34 N43:270 0 TCC Segment 3 Pressure Setpoint Pressure 3
CPC35 N43:271 0 TCC EndĆofĆSegment 3 Position Setpoint Incremental Distance 4
CPC37 N43:273 0 LPC Segment 1 Pressure Setpoint Pressure 3
CPC38 N43:274 0 LPC EndĆofĆSegment 1 Position Setpoint Incremental Distance 4
CPC40 N43:276 0 LPC Segment 2 Pressure Setpoint Pressure 3
CPC61 N43:297 * Start LPC Position Setpoint Incremental Distance 4
CPC62 N43:298 * Mold Safe Position Setpoint Incremental Distance 4
CPC63 N43:299 0 Tonnage Complete Pressure Setpoint Pressure 3
1 Clamp Percent of Maximum Velocity 2 Clamp Velocity along Axis 3 Clamp Pressure
00.00 to 99.99 00.00 to 99.99 Inches per Second 0000 to 9999 PSI
000.0 to 999.9 Bar
4 Clamp Axis Measured from MCC27 (if nonĆzero) or MCC23
00.00 to 99.99 Inches
00.00 to 999.9 Millimeters
* Refer to the appropriate section later in this chapter for information on this parameter
