Overview of the Remaining
Configuration Procedures
Chapter 3
4-5
Learn the following procedure because you will use it often.
1. For the block you want to download (subject block), get its ID
number from Table 4.A and enter it into DYC61.
Table 3.A
Information Required to Download a Command Block
Block to
Download:
ProĆSet 600
Block ID.:
ProĆSet 600
Download Bit B21/:
Companion
Block:
JGC 02 1
FCC 03 2 CPC
SCC 04 3 CPC
TCC 05 4 CPC
LPC 06 5 CPC
CPC 07 6
FOC 17 17 OPC
SOC 18 18 OPC
TOC 19 19 OPC
OSC 20 20 OPC
OPC 21 21
EAC 22 22 EPC
ERC 23 23 EPC
EPC 24 24
2. Confirm that the QDC module returns the ID in SYS61.
Important: If the value returned in SYS61 is NOT the ID number
you entered, you have an error in the MCC or DYC block:
If SYS61 has
this value:
This block
has errors:
Fix them as follows:
1 MCC Refer to chapter 3 Correct Any DataĆentry Errors in MCC"
25 DYC Go to steps 8 and 9 of this procedure.
Fix MCC and DYC errors before starting the download procedure
MCC and DYC errors are corrected when SYS61
≠
1 or 25, but
when SYS61=DYC61=ID number of the subject block
When you have done all three: Then:
1. Corrected all errors in MCC and DYC blocks
2. Entered the ID of the subject block in DYC61
3. Downloaded the subject block
The QDC module immediately
reports any programming errors it
detected in the subject block
