Rockwell Automation 1771-QDC, D17716.5.87(Passport) CLAMP AND EJECT MODE - Manual (Page 116)

Algorithm
0 = Vel/Pos
1 = Press/Pos
FCC SCC TCC
FCC SCC TCC
Logical Bridge
0 = Start Next Profile at end
1 = Stop and SetĆOutput at end
Mold Protection
0 = Start LPC on Zone Overrun
1 = Stop and Zero Outputs on Zone Overrun
Velocity Units
0 = Percent Velocity
1 = Inches (mm)/Second
CPC Block Identifier
Expert Response Compensation
0 = ON
1 = OFF
bit 15 = Press/Pos LPC
bit 13 = Press/Pos TCC
bit 12 = Vel/Pos TCC
bit 11 = Press/Pos SCC
bit 10 = Vel/Pos SCC
bit 09 = Press/Pos FCC
bit 08 = Vel/Pos FCC
Open/Closed Loop Selection
0 = Closed Loop
1 = Open Loop
bit 07 = Press/Pos LPC
bit 05 = Press/Pos TCC
bit 04 = Vel/Pos TCC
bit 03 = Press/Pos SCC
bit 02 = Vel/Pos SCC
bit 01 = Press/Pos FCC
bit 00 = Vel/Pos FCC
Code:
Your value
Required initial value
loaded by ProĆSet 600
0 or 1
Load Initial Profile Values for
Machine Tuning
Chapter 8
8-2
Worksheet 8ĆA
Clamp Close (CPC) Profile Block
Control Word CPC01ĆBxx 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
ProĆSet 600 Addr. B37/ bit 271 270 269 268 267 266 265 264 263 262 261 260 259 258 257 256
Value 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1
Control Word CPC03ĆBxx 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
ProĆSet 600 Addr. B37/bit 303 302 301 300 299 298 297 296 295 294 293 292 291 290 289 288
Value 0 1 0 0 0 0 0 0 0 0 0 1 0 1 0 1
Control Word CPC04ĆBxx 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
ProĆSet 600 Addr. B37/bit 319 318 317 316 315 314 313 312 311 310 309 308 307 306 305 304
Value 1 0 1 1 1 1 1 1 1 0 1 1 1 1 1 1
