Load Initial Profile Values for
Machine Tuning
Chapter 8
8-17
If the QDC module has control of all the valves in your ejector
circuit that are required to change the direction of ejector travel,
select 0 for bit 12 (the QDC module has the control capability during
the Ejector Profile to initiate each subsequent retract/advance stroke
upon completion of the preceding advance/retract stroke). Your PLC
ladder logic needs only to toggle DYC02-B14 (Pro-Set 600 address
B35/414) in order to command the QDC module to execute the entire
Ejector Profile. An example of this configuration is when the
direction of ejector travel is determined by a bi-directional flow
valve connected to the QDC module.
If the QDC module does not have control of all of the valves in your
ejector circuit that are required to change the direction of ejector
travel, select 1 for bit 12 (the QDC module does not have the control
capability during the Ejector Profile to initiate each subsequent
retract/advance stroke upon completion of the preceding
advance/retract stroke). Your PLC ladder logic has to operate the
ejector directional valves not connected to the QDC module in order
to “assist” the QDC module in its execution of the Ejector Profile.
The following is a partial list of the interactive command and status
bits that are provided to program a “Stop-and-Notify” Ejector Profile
in your PLC ladder logic.
Control Word: ProĆSet 600 address: Performs this action:
DYC02ĆB14
B35/414
Execute Ejector Profile
DYC03ĆB15
B35/431
Continue Ejector Profile
SYS03ĆB08
B35/40
Ejector Profile Stopped at EndĆof Stroke
SYS03ĆB10
B35/42
Ejector Forward Dwell Timer timing
SYS21ĆB14
B35/334
Ejector Profile in Progress
SYS22ĆB14
B35/350
Ejector EndĆof Advance setĆoutput in Progress
SYS22ĆB15
B35/351
Ejector EndĆof Retract setĆoutput in Progress
Refer to chapter 6 in this manual for additional information on this
type of ladder logic programming.
An example of the “Stop-and-Notify” configuration is when
direction of ejector travel is determined by discrete solenoid valves
connected to PLC outputs.
At this time, make the selection for bit 12 required by your ejector
hydraulic configuration.
