Configure the QDC Module's
Inputs and Outputs
Chapter 3
3-10
ATTENTION: As soon as you enable set-output operation, the
QDC module’s outputs drive the connected valves according to
the values you entered into DYC09 - DYC12 (Pro-Set 600
words N41:121 - N41:124). Be sure these values RESULT IN
NO MOVEMENT until you adjust them one-at-a-time with
your programming terminal in the procedures that follow.
Actuating the Clamp and Ejector with SetĆoutput Operation
1. Enter values that result in no motion in these DYC words:
Output: In Data Word: At ProĆSet 600
Address:
1 DYC09 N41:121
2 DYC10 N41:122
3 DYC11 N41:123
4 DYC12 N41:124
2. Enable set-output operation by entering a 1 in DYC01-B08 (Pro-Set
600 address B35/392). The QDC module sets outputs 1 - 4 to
percentage values that you entered in DYC09 - DYC12 respectively.
3. With your programming terminal, slowly increase the %-output value
of one output as you observe the corresponding movement.
Important: The DYC is constantly transferred to the QDC module by
Pro-Set 600 software, so changes you make to %-output values are
immediately implemented.
