Summary of Changes
Summary of Changes
We revised this publication to include changes due to upgrading the
1771-QDC/B module to a 1771-QDC/C.
For These Changes Refer to Page or Chapter
LossĆofĆsensor detection
input range changed back to 0.00 to 10V dc
3Ć6, 3Ć11
AĆ3, AĆ4
Added the section, Record I/O Ranges 2Ć1
Added data codes to configuration worksheets. Chapter 3 and Appendix A
Reversed the order of chapters 3 and 4 to present the
download procedure for the MCC block before the download
procedure for the other data blocks.
Revised the download procedure for the MCC block
(chapter 3) and for other command blocks (chapter 4).
Chapters 3 and 4
Changed the chapter title to better describe the task. Chapter 6
Added data codes to Configuration Block worksheets.
Added headers to improve the organization
Chapter 7 and Appendix A
Chapter 7
Added data codes to Profile Block worksheets.
Added headers to improve the organizatrion
Chapter 8 and Appendix A
Chapter 8
Placed 2Ćpage worksheets on facing pages Chapter 8
Changed the title Test Your Values to Test for Linearity. Chapter 9
Changed our recommendation on module calibration. 11Ć3
Added Block ID codes to blank worksheets. Appendix A
Revised the index. Index
Minor corrections as found
To Help You Find Changes
To help you find these changes, we added change bars as shown to the left.
Summary of Changes
