Using this Manual
Preface
P-5
Reference information for the QDC module is contained in a separate
document titled “Plastic Molding Module Reference Manual”. Take time
now to familiarize yourself with this reference manual’s content and
purpose. The four sections, in brief, include:
a summary of each data block used by the QDC module for all
command and status blocks (abbreviated command and status blocks)
the programming error codes returned by the QDC module on a block
by block basis as well as recommended procedures to correct these
errors
a detailed listing and explanation of each command word and bit used
by the QDC module, as well as each status word and bit returned from
the QDC module
operational, mechanical, electrical, and environmental specifications
about your module
If you have purchased the Pro-Set 600 software, you also need the
following documentation:
Publication #: Use this documentation: To:
6500Ć6.5.11 ProĆSet 600 Software
Designer's Guide
Select the ProĆSet 600 software that matches
the requirements of your molding machine.
6500Ć6.5.12 ProĆSet 600 Software
Assembly Manual
Transfer your ProĆSet 600 software from a
floppy to your hard drive. Add overlays into
your PLC processor and PanelView application
files.
6500Ć6.5.13 ProĆSet 600 Software
Overlay Installation Manual
Install ProĆSet 600 overlay(s) into your
application files.
6500Ć6.5.14 ProĆSet 600 Software
Customization Manual
Customize your ProĆSet 600 build for your
machine control requirements.
6500Ć6.5.15 ProĆSet 600 Software
Reference Manual
Support customizing your software
control system.
