Using Multi-Drive Mode

Chapter 7

The following Multi-drive parameters must be set in the master PowerFlex 525
drive:

Using Multi-Drive Add-On
Profile

Before using the Multi-drive Add-On Profile, ensure that you have completed the
following steps:

The master and daisy-chained drives are powered, networked, and
configured. See

System Wiring on page 85

.

The RS-485 network is configured. See

Configuring the RS-485 Network

on page 86

.

The controller has been added to the I/O configuration. See

Adding the

Controller to the I/O Configuration on page 38

.

Adding the Drive to the I/O Configuration

To transmit data between the controller and the drive, you must add the drive as a
child device to the parent controller. In this example, RSLogix 5000 version 20 is
used with drive Add-On Profile version 1.01 or later.

IMPORTANT

Parameters [Comm Loss Action] and [Comm Loss Time] in the daisy-chained
drives are still used in Multi-drive mode. If the RS-485 cable is disconnected or
broken, the disconnected drive(s) will take the corresponding Comm Loss
Action(s). On the EtherNet/ IP side, parameters C143 [EN Comm Flt Actn] and
C144 [EN Idle Flt Actn] determine the action taken for ALL of the drives on the
Multi-drive node.

Parameter

Value

P046 [Start Source 1]

5 “EtherNet/IP”

P047 [Speed Reference1]

15 “EtherNet/IP”

C169 [MultiDrv Sel]

0 “Disabled”
1 “Network Opt”
2 “EtherNet/IP”
Note: Drive must be power cycled after setting this
parameter.

C171 [Drv 1 Addr]

C124 [RS485 Node Addr] in Drive 1

C172 [Drv 2 Addr]

C124 [RS485 Node Addr] in Drive 2

C173 [Drv 3 Addr]

C124 [RS485 Node Addr] in Drive 3

C174 [Drv 4 Addr]

C124 [RS485 Node Addr] in Drive 4

C175 [DSI I/O Cfg]

0 “Drive 0”
1 “Drive 0-1”
2 “Drive 0-2”
3 “Drive 0-3”
4 “Drive 0-4”

IMPORTANT

Parameters can be set using a DSI peripheral (22-HIM-A3 or 22-HIM-C2S) only
when parameter C169 [MultiDrv Sel] is set to 0 “Disabled”.
