130 Rockwell Automation Publication 520COM-UM001B-EN-E - March 2013
Appendix C EtherNet/IP Objects
Instances (Multi-Drive)
36 Logic Status (read-only)
37 Reference (read/write)
38 Feedback (read-only)
(1) The mask command DWORD is set to the value of the first DWORD of the data where there are ones in the second DWORD of the
data. Only the bits of the Logic Command that have the corresponding mask bit set are applied.
Instance Description
1 Status Image – All I/O data being read from the embedded adapter (read-only)
2 Command Image – All I/O data written to the embedded adapter (read/write)
3 Logic Status and Feedback 0 (read-only)
4 Logic Command and Reference 0 (read/write)
5 Logic Status and Feedback 1 (read-only)
6 Logic Command and Reference 1 (read/write)
7 Logic Status and Feedback 2 (read-only)
8 Logic Command and Reference 2 (read/write)
9 Logic Status and Feedback 3 (read-only)
10 Logic Command and Reference 3 (read/write)
11 Logic Status and Feedback 4 (read-only)
12 Logic Command and Reference 4 (read/write)
13 Logic Command, all drives (Masked)
(1)
(read/write)
(1) The mask command DWORD is set to the value of the first DWORD of the data where there are ones in the second DWORD of the
data. Only the bits of the Logic Command that have the corresponding mask bit set are applied.
14 Logic Command 0 (Masked) (1) (read/write)
15 Logic Command 1 (Masked) (1) (read/write)
16 Logic Command 2 (Masked)
(1)
(read/write)
17 Logic Command 3 (Masked)
(1)
(read/write)
18 Logic Command 4 (Masked) (1) (read/write)
19 Logic Status 0 (read-only)
20 Logic Command 0 (read/write)
21 Feedback 0 (read-only)
22 Reference 0 (read/write)
23 Logic Status 1 (read-only)
24 Logic Command 1 (read/write)
25 Feedback 1 (read-only)
26 Reference 1 (read/write)
27 Logic Command 2 (read/write)
28 Logic Status2 (read-only)
29 Reference 2 (read/write)
30 Feedback 2 (read-only)
31 Logic Command 3 (read/write)
32 Logic Status 3 (read-only)
33 Reference 3 (read/write)
34 Feedback 3 (read-only)
35 Logic Command 4 (read/write)
36 Logic Status 4 (read-only)
37 Reference 4 (read/write)
38 Feedback 4 (read-only)
Instance Description
