Rockwell Automation Publication 520COM-UM001B-EN-E - March 2013 149
EtherNet/IP Objects Appendix C
TCP/IP Interface Object Class Code
Services
Instances
The adapter supports one instance of the TCP/IP Interface object.
Class Attributes
Instance Attribute
Hexadecimal Decimal
0xF5 245
Implemented for:
Service Code Class Instance Service Name
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Number Description
0 Class Attribute
1 Object Attribute
Attribute ID Access Rule Name Data Type Description
1 Get Class Revision UINT The revision of this object
Attribute ID Access Rule Name Data Type Description
1 Get Status of TCP/IP Network Interface UDINT 0 = Not configured
1 = Valid configuration
2…15 = Reserved
2 Get Configuration Capability UDINT Bit | Value (0 = False, 1 = True)
0 = Supports BOOTP
1 = DNS Client (able to resolve host names by query to DNS server)
2 = DHCP Client (able to obtain network configuration through DHCP)
3 = DHCP-DNS Update (able to send its host name in the DHCP request)
4 = Configuration Settable (able to set the network configuration using TCP/
IP object)
5…31 = Reserved
3 Set Configuration Control UDINT Bit | Value
1…3 = Startup configuration
0 = Use configuration saved in NVS
1 = Obtain configuration using BOOTP
2 = Obtain configuration using DHCP
3…15 = Reserved
4 = DNS Enabled (resolves host names by query to DNS server)
5…31 = Reserved
