Rockwell Automation Publication 520COM-UM001B-EN-E - March 2013 21
Setting Up the Adapter Chapter 2
For more information on how to set different combinations of the control and
Reference functions, see the PowerFlex 525 drive user manual,
publication
520-UM001 .
Commissioning the Adapter To commission the embedded EtherNet/IP adapter, you must set a unique IP
address. See the
Glossary for details about IP addresses. Use either a BOOTP
server or parameters to set the IP address after connecting the adapter to the
network and applying power to the drive.
By default, the adapter is configured to accept an IP address from a BOOTP
server. For details, see
Using BOOTP on page 26 . To set the IP address using
parameters, see Setting the IP Address, Subnet Mask, and Gateway Address on
page 29 .
IMPORTANT New settings for some parameters (for example, parameters C129 [EN IP
Addr Cfg 1] through C132 [EN IP Addr Cfg 4]) are recognized only when
power is applied to the adapter. After you change parameter settings, cycle
drive power.
