146 Rockwell Automation Publication 520COM-UM001B-EN-E - March 2013
Appendix C EtherNet/IP Objects
Formulas for Converting
Display Value = ((Internal Value + Offset) x Multiplier x Base) / (Divisor x 10 Decimal Places ))
Internal Value = ((Display Value x Divisor x 10
Decimal Places
) / (Multiplier x Base)) - Offset
Common Services
Object Specific Services
The table below lists the parameters for the Get_Attributes_Scattered and
Set_Attributes_Scattered object-specific service:
The response data appears in the following format:
Implemented for:
Service Code Class Instance Service Name
0x0E Yes Yes Get_Attribute_Single
0x10 Yes Yes Set_Attribute_Single
Implemented for: Allocation Size (in bytes)
Service Code Class Instance Service Name Par. Number Par. Value
0x32 Yes No Get_Attributes_Scattered 4 4
0x34 Yes Yes Set_Attributes_Scattered 4 4
Name Data Type Description
Parameter Number UDINT Parameter to read or write
Parameter Value UDINT Parameter value write (zero when reading)
Name Data Type Description
Parameter Number UDINT Parameter read or write (1)
(1) If an error occurred, bit 15 will be turned on in the response.
Parameter Value UDINT Parameter value read (zero when writing)
(2)
(2) If an error occurred, the error code will appear instead of the value.
