Rockwell Automation Publication 520COM-UM001B-EN-E - March 2013 129
EtherNet/IP Objects Appendix C
Register Object Class Code
Services
Instances (Single-Drive)
Hexadecimal Decimal
0x07 7
Implemented for:
Service Code Class Instance Service Name
0x0E Yes Yes Get_Attribute_Single
0x10 Yes Yes Set_Attribute_Single
Instance Description
1 Status Image – All I/O data being read from the embedded adapter (read-only)
2 Command Image – All I/O data written to the embedded adapter (read/write)
3 Logic Status and Feedback (read-only)
4 Logic Command and Reference (read/write)
5 Datalink To Net 1 (read only)
6 Datalink From Net 1 (read/write)
7 Datalink To Net 2 (read only)
8 Datalink From Net 2 (read/write)
9 Datalink To Net 3 (read only)
10 Datalink From Net 3 (read/write)
11 Datalink To Net 3 (read only)
12 Datalink From Net 4 (read/write)
13 Logic Command (Masked)
(1)
(read/write)
14 Logic Command (Masked) (1) (read/write)
15 Logic Command (Masked) (1) (read/write)
16 Logic Command (Masked)
(1)
(read/write)
17 Logic Command (Masked)
(1)
(read/write)
18 Logic Command (Masked) (1) (read/write)
19 Logic Status (read-only)
20 Logic Command (read/write)
21 Feedback (read-only)
22 Reference (read/write)
23 Logic Status (read-only)
24 Logic Command (read/write)
25 Feedback (read-only)
26 Reference (read/write)
27 Logic Command (read/write)
28 Logic Status (read-only)
29 Reference (read/write)
30 Feedback (read-only)
31 Logic Command (read/write)
32 Logic Status (read-only)
33 Reference (read/write)
34 Feedback (read-only)
35 Logic Command (read/write)
