30 Rockwell Automation Publication 520COM-UM001B-EN-E - March 2013
Chapter 3 Configuring the Adapter
Setting a Subnet Mask Using Parameters
1. Verify that parameter C128 [EN EN Addr Sel] is set to 1“Parameters”.
This parameter must be set to “Parameters” to configure the subnet mask
using parameters.
2. Set the value of parameters C133 [EN Subnet Cfg 1] through C136 [EN
Subnet Cfg 4]
to the desired value for the subnet mask.
3. Reset the adapter by power cycling the drive.
Setting a Gateway Address Using Parameters
1. Verify that parameter C128 [EN EN Addr Sel] is set to 1“Parameters”.
This parameter must be set to “Parameters” to configure the gateway
address using parameters.
2. Set the value of parameters C137 [EN Gateway Cfg 1] through C140
[EN Gateway Cfg 4]
to the desired value for the gateway address.
3. Reset the adapter by power cycling the drive.
Setting the Data Rate By default, the adapter automatically detects the data (baud) rate and duplex
setting used on the network. If you need to set a specific data rate and duplex
setting, the value of parameter C141 [EN Rate Cfg] determines the Ethernet
data rate and duplex setting that the adapter will use to communicate. For
definitions of data rate and duplex, see the
Glossary .
1. Set the value of parameter C141 [EN Rate Cfg] to the data rate at which
your network is operating.
Default = 0.0.0.0 255.255.255.0
[EN Subnet Cfg 1]
[EN Subnet Cfg 2]
[EN Subnet Cfg 3]
[EN Subnet Cfg 4]
Default = 0.0.0.0 192.168.1.1
[EN Gateway Cfg 1]
[EN Gateway Cfg 2]
[EN Gateway Cfg 3]
[EN Gateway Cfg 4]
Options 0 “Auto detect” (Default)
1 “10Mbps Full”
2 “10Mbps Half”
3 “100Mbps Full”
4 “100Mbps Half”
