132
Rockwell Automation Publication 520COM-UM001B-EN-E - March 2013
Appendix C
EtherNet/IP Objects
Parameter Object
Class Code
Services
Instances (Single-Drive)
Instances (Multi-Drive)
Hexadecimal
Decimal
0x0F
15
Implemented for:
Service Code
Class
Instance
Service Name
0x01
Yes
Yes
Get_Attribute_All
0x05
Yes
No
Reset
0x0E
Yes
Yes
Get_Atribute_Single
0x10
No
Yes
Set_Attribute_Single
0x4B
No
Yes
Get_Enum_String
Instance
Description
0
Class
1
Drive Parameter 1
...
...
n
Drive Parameter n
(1)
(1) n represents the number of parameters in the drive.
Instance
Description
0
Class (Drive 0)
1
Drive 0 Parameter 1
...
...
n
Drive 0 Parameter n
(1)
(1) n represents the number of parameters in the drive.
16384
Class (Interface
(2)
)
(2) Interface is the current interface being used to access the information. Note: If using the embedded EtherNet/IP adapter, this
instance range contains the same data as Drive 0.
16384 + 1
Interface Parameter 1
...
...
16384 + n
Interface Parameter n
(1)
17408
Class (Drive 1)
17408 + 1
Drive 1 Parameter 1
...
...
17408 + n
Drive 1 Parameter n
(1)
18432
Class (Drive 2)
18432 + 1
Drive 2 Parameter 1
...
...
18432 + n
Drive 2 Parameter n
(1)
19456
Class (Drive 3)
19456 + 1
Drive 3 Parameter 1
...
...
19456 + n
Drive 3 Parameter n
(1)
20480
Class (Drive 4)
20480 + 1
Drive 4 Parameter 1
...
...
20480 + n
Drive 4 Parameter n
(1)
