Configuring the Adapter Chapter 3
9. To assign this configuration to the adapter, select the device in the Relation
List and click Disable BOOTP/DHCP. When power is cycled on the
drive, the adapter will use the configuration you assigned it and not issue
new BOOTP/DHCP requests.
10. To save the Relation List, select File > Save.
Setting the IP Address,
Subnet Mask, and Gateway
Address By default, the adapter is configured to accept an IP address, subnet mask, and
gateway address from a BOOTP server. If you want to set these attributes using
parameters instead, you must first disable BOOTP and then set these network
address parameters in the drive.
Disabling the BOOTP Feature
1. Set the value of parameter C128 [EN Addr Sel] to 1“Parameters”.
2. Reset the adapter by power cycling the drive.
After disabling the BOOTP feature, you can then configure the IP
address, subnet mask, and gateway address using parameters.
Setting an IP Address Using Parameters
1. Verify that parameter C128 [EN Addr Sel] is set to 1“Parameters”. This
parameter must be set to “Parameters” to configure the IP address using
parameters.
2. Set the value of parameters C129 [EN IP Addr Cfg 1] through C132
[EN IP Addr Cfg 4]
to a unique IP address.
3. Reset the adapter by power cycling the drive.
TIP To enable BOOTP for an embedded adapter that has had BOOTP
disabled, first select the adapter in the Relation List. Then click Enable
BOOTP and power cycle the drive.
Options 1 “Parameters”
2 “BOOTP” (Default)
192.168.1.62
[EN IP Addr Cfg 1]
[EN IP Addr Cfg 2]
[EN IP Addr Cfg 3]
[EN IP Addr Cfg 4]
Default = 0.0.0.0
