Configuring the Adapter
Chapter 3
Using the PowerFlex 4-Class
HIM to Access Parameters
The PowerFlex 4-class HIM can be used to access parameters in the drive (see
basic steps shown below). It is recommended that you read through the steps for
your HIM before performing the sequence. For additional HIM information,
refer to the HIM Quick Reference card, publication
Step
Key(s)
Example Display
1.
Power up the drive. Then connect the HIM
to the DSI port of the drive. The Parameters
tab for the drive will be displayed.
2.
Select Groups in the Parameters tab if it is
not already selected using the Up Arrow or
Down Arrow.
Press Enter to select Groups.
3.
Press Sel repeatedly until the C tab
(Communications parameters) is selected.
4.
Press the Up Arrow or Down Arrow to scroll
to the Communications parameter you
wish to display or modify, then press Enter.
Parameters
Groups
Linear List
Changed Params
DIAG
PARAM
DSEL
MEM
SEL
and
Basic Display
001 Output Freq
002 Commanded Freq
003 Output Current
004 Output Voltage
005 DC Bus Voltage
B
P
T
C
SEL
Sel
Communications
121 Comm Write Mode
122 Cmd Stat Select
123 RS485 Data Rate
124 RS485 Node Addr
125 Comm Loss Action
B
P
T
C
SEL
and
Communications
121 Comm Write Mode
122 Cmd Stat Select
123 RS485 Data Rate
124 RS485 Node Addr
125 Comm Loss Action
B
P
T
C
SEL
RS485 Data Rate
Parameter:
#
123
9600
3
VALUE
LIMITS
SEL
