Rockwell Automation 25B PowerFlex 525 Embedded EtherNet/IP Adapter User Manual
Page 42
42
Rockwell Automation Publication 520COM-UM001B-EN-E - March 2013
Chapter 4
Configuring the I/O
3.
On the General tab, edit the following data about the drive:
4.
On the New Module window in the Module Definition section, click
Change…
to launch the Module Definition window and begin the drive
configuration process.
Box
Setting
Name
A name to identify the drive.
Description
Optional – description of the drive.
IP Address
The IP address of the adapter.
